Short Description
China EBM PAPST AC Centrifugal Fan Supplier Honest provides R2E220-AD19-11 AC Centrifugal Fans, shaft horizontal or rotor on bottom or top on request.
Keywords: Centrifugal Fan,
 |
EBM PAPST AC Centrifugal Fan, R2E220-AD19-11 Key Specifications / Features
Type: R2E220-AD19-11
Motor: M2E068-CA
Motor: M2E068-CA
| Phase | 2~ | 2~ | |
| Nominal voltage | VAC | 415 | 415 |
| Frequency | Hz | 50 | 60 |
| Type of data definition | Fa | Cs | |
| Valid for approval/ standard | CE | CE | |
| Speed | Min-1 | 2570 | 2750 |
| Power input | W | 88 | 100 |
| Current draw | A | 0.22 | 0.25 |
| Motor capacitor | µF | 0.68 | 0.68 |
| Capacitor voltage | VDB | 700 | 700 |
| Capacitor standard | P0 (CE) | P0 (CE) | |
| Min. back pressure | Pa | 0 | 0 |
| Max. ambient temperature | ℃ | 55 | 55 |
Technical Features:
| Mass | 1.6kg |
| Size | 220 mm |
| Surface of rotor | Coated in black |
| Material of impeller | Plastic PA6, fiberglass-reinforced |
| Number of blades | 11 |
| Direction of rotation | Clockwise, seen on rotor |
| Type of protection | IP44, depending on installation and position as per EN60034-5 |
| Insulation class | “F” |
| Humidity class | F2-2 |
| Max. permissible ambient motor temp. (transp./ storage) | +80℃ |
| Min. permissible ambient motor temp. (transp./ storage) | -40℃ |
| Mounting position | Shaft horizontal or rotor on bottom, rotor on top on request |
| Condensate discharge holes | Rotor-side |
| Operation mode | S1 |
| Motor bearing | Ball bearing |
